ALU SONA

$5,670.00

Production takes 6 weeks

This door features R-Value 8.3 thermal insulation, 30dB sound insulation, and triple glazing for enhanced comfort. The FUHR 855GL multi-point lock ensures 7-point security with 2 hooks and 4 bolts. The set includes an aluminum frame, stainless steel handle, 3-part roller hinges, and an anti-burglary lock insert with 5 keys.

ALU Alu Single Door ALUMINIUM COLLECTIONS SINGLE ALU DOOR with glass in door with sidelight
Open Configurator

Returning to the model selection will restart the remaining options. Do you want to continue?

Close

MODEL

LAYOUT

OPENING WAY

COLOR

DOOR HEIGHT
WITH  FRAME

DOOR WIDTH
WITH  FRAME

ACCESSORIES

HANDLES

Woods
Colors


Wood color options are available upon request; however, please note that availability may vary depending on the specific model and size. Not all products in our catalog support wood textures due to design or material limitations.
If you are interested in a wood finish, we encourage you to contact us via email with the product name, size, and any preferred color or texture. Our team will be happy to check availability and assist you with customization options.

Your model: ALU SONA
y
x
handle
y
x
x
y
x
handle
y
x
x

Select all options in the configurator before adding the door to the cart

Product total
Options total
Grand total

FREE SHIPPING!

This high-performance door combines excellent thermal insulation (R-Value 8.3) and sound insulation (30dB), making it a perfect choice for energy efficiency and noise reduction. It features 2.7″ thick polyurethane foam and triple glazing, providing optimal protection against outdoor elements.

For security, the door is equipped with the FUHR 855GL multi-point locking system, offering 7 locking points—2 hooks, 4 bolts, and an upper bolt—to ensure maximum anti-burglary protection. The set includes a durable aluminum frame, a sleek stainless steel handle, and 3-part roller hinges in the same color as the door for smooth and reliable operation.

Additionally, it comes with a 0.6″ threshold strip and an anti-burglary class lock insert that includes 5 keys for added security. Available in various sizes, this door provides a perfect balance of security, insulation, and modern design.

ALU Doors



Profile Construction

Made entirely from aluminum, ALU doors are lightweight, corrosion-resistant, and exceptionally durable. The profile is insulated with foam and coated with aluminum, providing excellent thermal performance and a sleek, modern look.

Technical Specifications & Set Inclusions

  • Production & Delivery: Approximately 6 weeks for production + 1.5 weeks for delivery.
  • Warranty: 5-year manufacturer warranty.
  • Frame Size: The aluminum door frame is 2.8 inches (approx. 71 mm) thick.
  • Available Dimensions (Single Door with Frame):
    • Width: from 900mm to 1550mm
    • Height: from 2000mm to 2860mm
  • Locking System: The door set includes a multi-point lock system. A detailed view of the system is available on the manufacturer’s website.
  • The door set includes:
    • Aluminum door and door frame.
    • High-quality door handle.
    • Adjustable hinges.
    • Multi-point locking system.
    • Threshold strip (detailed dimensions and pictures available).
    • Standard lock insert with 5 keys.

Glazing

The glass in our doors features triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1.

  • Standard Glazing Package: 4th/16Ar/4/16Ar/4th
  • Safety Glass: VSG 33.1 // 4 // 4
  • P4 Anti-burglary Glass

A wide range of glass options is available, including energy-saving, sound-absorbing, safety, anti-burglary, and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass, as well as bronze reflex glass.

Light Permeability: Milk (Frosted) Glass: 89%; Mirror Glass: 68%; Graphite Reflex Glass: 42%.

Colours

ALU doors are available in a wide selection of colors from the RAL palette, allowing for perfect customization to match any architectural style.

Wala Hidden Hinges

We use Wala hidden hinges that combine high durability, numerous assembly advantages and a discreet, elegant form. Hinges are invisible when the door is closed. The 3D adjustment function provides a convenient way of adjusting the pressure, height and side adjustment (left/right) of the door. Hinges allow for trouble-free installation and removal of the door leaf/slab. Depending on the door height there are at least 3 hinges per door leaf/slab.

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2″ to 0.2″, gap: -2.5 to 2.5 mm / -0.1″ to 0.1″ , seal pressure: -1.5 to 1.5 mm / -0.05″ to 0.05″ . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.

Wala Hidden Hinges

We use Wala hidden hinges that combine high durability, numerous assembly advantages and a discreet, elegant form. Hinges are invisible when the door is closed. The 3D adjustment function provides a convenient way of adjusting the pressure, height and side adjustment (left/right) of the door. Hinges allow for trouble-free installation and removal of the door leaf/slab. Depending on the door height there are at least 3 hinges per door leaf/slab.

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2″ to 0.2″, gap: -2.5 to 2.5 mm / -0.1″ to 0.1″ , seal pressure: -1.5 to 1.5 mm / -0.05″ to 0.05″ . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.


Type of door

Double door's, Single door
