FUSION PRESCOTT

$3,380.00

Production takes 4 weeks

The PRESCOTT offers enhanced security, excellent thermal insulation, and superior soundproofing. It comes prehung and features a dual sealing system, multi-point locking, and reinforced hinges.

F SINGLE STAINLESS DOOR FUSION STAINLESS STEEL DOOR'S COLLECTIONS with glass in door with panels with sidelight
Open Configurator

Returning to the model selection will restart the remaining options. Do you want to continue?

Close

MODEL

LAYOUT

OPENING WAY

COLOR

DOOR HEIGHT
WITH  FRAME

DOOR WIDTH
WITH  FRAME

ACCESSORIES

HANDLES

Woods
Colors


Wood color options are available upon request; however, please note that availability may vary depending on the specific model and size. Not all products in our catalog support wood textures due to design or material limitations.
If you are interested in a wood finish, we encourage you to contact us via email with the product name, size, and any preferred color or texture. Our team will be happy to check availability and assist you with customization options.

Your model: FUSION PRESCOTT
y
x
handle
y
x
x
y
x
handle
y
x
x

Select all options in the configurator before adding the door to the cart

Product total
Options total
Grand total

FREE SHIPPING!

The PRESCOTT is designed for high performance, durability, and security. Made from premium stainless steel, the door slab is filled with PUR polyurethane foam and wood to enhance its insulation properties. With a 2.1-inch thick slab, this door offers solid construction and superior energy efficiency.

The dual sealing system includes seals both in the dap of the frame and in the supporting part of the door slab, ensuring maximum thermal insulation and reducing vibrations. These seals also protect against heat loss and remain stable despite changing environmental conditions. The door frame is reinforced with anti-burglar protection in the hinge and locking points to enhance its security.

The door set includes the multi-point locking system with two independent locks that provide comprehensive anti-theft security. Additionally, the door features six adjustable anti-burglary hinges (three on each side), an aluminum threshold with a gasket, and three anti-theft bolts for extra protection. Two sets of key inserts and a normal door handle (with a long T-bar handle option) complete the package. For solid doors, a viewfinder is also included.

For thermal and sound insulation, the R-Value is 5.7 for solid doors and 5.3 for glazed doors. The door also provides 31 dB of acoustic insulation, making it ideal for noise-sensitive areas. Triple glazing is used in the glass doors to ensure excellent soundproofing and thermal performance.

The PRESCOTT is prehung on the frame, making installation easy and efficient. It comes fully assembled and ready to be mounted, reducing the time and effort required for setup.

FUSION Doors

Profile Construction

The FUSION collection features a hybrid construction with a durable aluminum frame and a stainless steel door panel. The door is insulated with foam and wood and covered in a stainless steel sheet, combining modern aesthetics with robust performance.

Technical Specifications & Set Inclusions

  • Production & Delivery: Approximately 8 weeks for production + 1.5 weeks for delivery.
  • Warranty: 2-year manufacturer warranty.
  • Frame Size: The FUSION door frame is 78 mm thick.
  • Available Dimensions (Single Door with Frame):
    • Width: from 901mm to 1151mm
    • Height: from 2000mm to 2400mm
  • Locking System: The door set includes a multi-point lock system.
  • The door set includes:
    • Aluminum/Stainless steel door and door frame.
    • High-quality door handle.
    • Adjustable hinges.
    • Multi-point locking system.
    • Threshold strip (detailed dimensions and pictures available).
    • Standard lock insert with 5 keys.

Glazing

The glass in our doors features triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1.

  • Standard Glazing Package: 4th/16Ar/4/16Ar/4th
  • Safety Glass: VSG 33.1 // 4 // 4
  • P4 Anti-burglary Glass

A wide range of glass options is available, including energy-saving, sound-absorbing, safety, anti-burglary, and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass, as well as bronze reflex glass.

  • Light Permeability: Milk (Frosted) Glass: 89%; Mirror Glass: 68%; Graphite Reflex Glass: 42%.

Colours

The FUSION collection is available in a range of standard RAL colors:

  • Anthracite: RAL 7016
  • White structure: RAL 9003
  • Black matt: RAL 9005
  • Swamp oak: RAL 8028
  • Golden oak: RAL 8003
  • Bleached oak: RAL 1019
  • Winchester: RAL 8001
  • Anthracite: RAL 7015
  • Anthracite sapphire: RAL 7011
  • Silver gray: RAL 7040

Wala Hidden Hinges

We use Wala hidden hinges that combine high durability, numerous assembly advantages and a discreet, elegant form. Hinges are invisible when the door is closed. The 3D adjustment function provides a convenient way of adjusting the pressure, height and side adjustment (left/right) of the door. Hinges allow for trouble-free installation and removal of the door leaf/slab. Depending on the door height there are at least 3 hinges per door leaf/slab.

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2″ to 0.2″, gap: -2.5 to 2.5 mm / -0.1″ to 0.1″ , seal pressure: -1.5 to 1.5 mm / -0.05″ to 0.05″ . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.


Opening way:

Left hand – opening to inside, Left hand reverse – opening to outside, Right hand – opening to inside, Right hand reverse – opening to outside
Door height with frame:

80" +$110.00, 82.3", 82" +$112.00, custom height from 70.7" to 82.3" +$110.00
Glazing:

Graphite reflex, Milk frosted glass, Mirror glass, Standard ( transpared – clear glass )
Color:

Black + $110.00, Bleached oak + $110.00, Concrete + $110.00, Corten – architectural rust + $110.00, Dark anthracite RAL 7016, Double color ( doors in different colors inside and outside ), Golden oak, Light anthracite ( silver grey ) RAL 7040, Mahogany, Smooth anthracite RAL 7015, Turners oak, Walnut, Wenge, White, Winchester
Rain deflector:

No, Yes + $40.00
T-bar - long vertical handle or normal handle:

Only a normal door handle black + $70.00, Only a normal door handle silver, Yes, T-bar Straight, circular shape 47.2" black + $320.00, Yes, T-bar Straight, circular shape 47.2" silver + $270.00, Yes, T-bar Straight, rectangular shape 63" black + $320..00, Yes, T-bar Straight, rectangular shape 63" silver + $280.00
The color of the frame around the glass:

Black, Silver
