The Nilo pivot door combines aluminum construction with high-security features and thermal efficiency. With FUHR 833 3-point locking, it ensures a safe, insulated entry for your home or business.
NILO
$11,170.00
Production takes 7 weeks
ALUMINIUM COLLECTIONS PIVOT SINGLE PIVOT DOOR with sidelight
Open Configurator
Close
Woods
Colors
Wood color options are available upon request; however, please note that availability may vary depending on the specific model and size. Not all products in our catalog support wood textures due to design or material limitations.
If you are interested in a wood finish, we encourage you to contact us via email with the product name, size, and any preferred color or texture. Our team will be happy to check availability and assist you with customization options.
Your model: NILO
y
x
y
x
x
y
x
y
x
x
Select all options in the configurator before adding the door to the cart
FREE SHIPPING!
NILO – Premium Pivot Door for Modern Homes and Commercial Spaces
The NILO pivot door is a sophisticated, high-performance solution designed to meet the demands of modern architecture. Crafted from durable aluminum and enhanced with triple-glazed glass, it delivers exceptional thermal insulation, security, and aesthetic appeal. Its bold design, clean lines, and flush-mounted construction make it a striking focal point for any entryway.
Customizable Sizes for a Perfect Fit
Available in widths ranging from 55.1″ to 72″ and heights from 78.7″ to 116″, the NILO door can be tailored to fit both residential and commercial buildings. Whether you’re updating your home or designing a modern storefront, this door adapts seamlessly to various architectural requirements.
Outstanding Thermal and Acoustic Insulation
The insulated aluminum structure, combined with high-performance triple glazing, provides an R-Value of 5.5, ensuring excellent energy efficiency. In addition, the door offers effective sound reduction, making your interior spaces quieter and more comfortable.
Advanced Technical Specifications
Engineered for harsh environments and high-security needs, the NILO pivot door excels in:
-
Air tightness: 600 Pa
-
Water resistance: 150 Pa
-
Wind load resistance: 1200 Pa
-
Burglar resistance: RC2 / WK2
These ratings ensure lasting durability and peace of mind, even in challenging weather conditions.
Complete Door Set Includes:
-
Premium aluminum pivot door
-
FUHR 833 3-point locking system for enhanced protection
-
Low-profile threshold for barrier-free entry
-
Modern handle
-
Lock insert with 5 keys for convenience
Why Choose the NILO Door?
The NILO pivot door is more than just an entrance—it’s a statement of style and performance. With its seamless operation, outstanding insulation, and advanced locking system, it’s ideal for anyone who values design without compromising on security or efficiency.
PIVOT Doors
Profile Construction
Made entirely from aluminum, PIVOT doors offer a unique and grand entrance with an offset pivot point. The profile is insulated with foam and coated with aluminum, ensuring thermal efficiency, durability, and a striking contemporary appearance ideal for large openings.
Technical Specifications & Set Inclusions
- Production & Delivery: Approximately 6 weeks for production + 1.5 weeks for delivery.
- Warranty: 5-year manufacturer warranty.
- Frame Size: The PIVOT door frame is 3 inches (approx. 76 mm) thick.
- Available Dimensions: PIVOT doors are typically made for custom, often oversized, dimensions to create a statement entrance.
- Locking System: The door set includes a multi-point lock system suitable for large-format doors.
- The door set includes:
- Aluminum door and door frame.
- High-quality door handle.
- Specialized pivot hinge system.
- Multi-point locking system.
- Threshold strip (detailed dimensions and pictures available).
- Standard lock insert with 5 keys.
Glazing
The glass in our doors features triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1.
- Standard Glazing Package: 4th/16Ar/4/16Ar/4th
- Safety Glass: VSG 33.1 // 4 // 4
- P4 Anti-burglary Glass
A wide range of glass options is available, including energy-saving, sound-absorbing, safety, anti-burglary, and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass, as well as bronze reflex glass.
- Light Permeability: Milk (Frosted) Glass: 89%; Mirror Glass: 68%; Graphite Reflex Glass: 42%.
Colours
PIVOT doors are available in a wide selection of colors from the RAL palette, allowing for full customization to complement the architectural vision.
Multipoint locking system Fuhr 835
Automatic multipoint locking system with a deadlocking latch.
Fuhr lock is the excellent locking system that guarantees comfort as well as security. The lock function ensures reliable, automatic locking and protection against uninvited guests. All you have to do is pull the door closed.
After closing the door, our three-point locking system protects against door warping, offering long-lasting seal tightness and a thermal efficiency.
The most important features:
Increased security – due to automatic locking there is no need for conventional locking with using a key.
Convenient opening – Effortless key operation thanks to two-stage opening sequence from the outside or using the lever handle from the inside.
Increased heat insulation – The multipoint locking system prevents the door from warping to ensure consistent seal tightness around the whole door leaf/slab.
Reliability and durability – long service life is guaranteed and has been tested with over 200,000 cycles.
Locking the lock:
- After closing the door, the latch in the main lock and additional bolts automatically lock the door.
- A single turn of the key causes the bolt of the main lock to be activated.
Unlocking the lock:
- Turning the key once withdraws both lock and bolts. Pressing the handle down causes the latch to be automatically released and allows to open the door.
| Type of door | Double door's, Single door |
|---|
